AGR420 - 2.4T Aggregation Router
AGR420 - 2.4T Aggregation Router
AGR420 - 2.4T Aggregation Router
AGR420 / AS7946-74XKSB

AGR420 - 2.4T Aggregation Router

Manufacturer: Edgecore

Delivers to:

Delivers to Europe.

Contact us for volume discounts.

Authorized Distributor

Stock Availability

Volume Discounts

Technical Support

Includes Warranty

Product Detail

AGR420 is a high performance 25GbE aggregation router that consists of fixed 64 x 10G/25G SFP28, 8 x 100GE QSFP28 and 2 x 100G QSFP-DD (supporting high power optics only, compatible with QSFP28 also) network interface configuration with External BCM16K Lookup Engine enables the 2RU compact design to be deployed as a disaggregated or standalone router. The BCM16K Knowledge-Based Processor (KBP) performs high-speed operations on large-rule databased for a wide range of telecommunications applications. It provides network awareness, enables real-time modifications, and updates to the routing configuration, making it ideal for packet classification, policy enforcement, and forwarding.

AGR420 is engineered with the latest Broadcom StrataDNX™ Qumran2C silicon with an external lookup engine that target for use cases including OpenBNG, 25G pre-aggregation router, PE router or data center TOR switch/router. This open networking router is loaded with the Open Network Install Environment (ONIE), which supports the installation of compatible Network Operating System (NOS) soſtware, including the open source option Open Network Linux (ONL), plus commercial NOS offerings.

AGR420 - 2.4T Aggregation Router
64 x 10G/25G, 8/2 x 100G with Qumran 2C. High-performance 25GbE leaf router for telecom and data center applications.
AGR420 / AS7946-74XKSB
AGR420 / AS7946-74XKSB

Pricing Table

Technical Specification

Data Rate:
Predominant Port Type:
10G/25G SFP28
Product Highlights:
  • High performance 25GbE router for Telecom and Data Center applications
  • Incorporates Broadcom StrataDNX™ Qumran2C Silicon
  • Integrated BCM16K External Lookup Table for expansion
  • Supports Front-to-Back Airflow SKU
  • Hot-Swappable, Load-sharing, and 1+1 redundant DC-DC/AC-DC PSUs
  • 4+1 Redundant, Hot-Swappable Fan Modules
  • Support Synchronous Ethernet(SyncE), and IEEE 1588v2 PTP
  • Compatible with Casa software
  • Compatible with IP Infusion OcNOS
  • Compatible with RtBrick Full Stack OS




Edgecore Networks Corporation is a wholly-owned subsidiary of Accton Technology Corporation, the leading network ODM.  Edgecore Networks delivers wired and wireless networking products and solutions through channel partners and system integrators worldwide for data center, service provider, enterprise, and SMB customers.
