S9701-82DC - 25/100G Disaggregated Core and Edge Router
S9701-82DC - 25/100G Disaggregated Core and Edge Router
S9701-82DC - 25/100G Disaggregated Core and Edge Router
ufiSpace
S9701-82DC

S9701-82DC - 25/100G Disaggregated Core and Edge Router

Manufacturer: ufiSpace

Datasheet: S9701-82DC

Delivers to:

Delivers to Europe.

Contact us for volume discounts.

Status:


Authorized Distributor

Stock Availability

Volume Discounts

Technical Support

Includes Warranty

Product Detail

The UfiSpace S9701-82DC is a high density 25GE disaggregated open router that evolves the network and enables next generation of 5G services and applications. The S9701-82DC can be deployed as a standalone device or within a core switching cluster as a "line card" element within the distributed disaggregated chassis, also known as a DDBR (Distributed Disaggregated Backbone Router).
As a standalone router, the S9701-82DC provides the service ports needed to enable multiple edge transport service aggregation over a scalable next generation service provider network. It is also suitable for central office data centers and general network aggregation.
When coupled with UfiSpace's fabric switch (S9705-48D), the S9701-82DC becomes a building block for the distributed disaggregated chassis (DDC). The DDC allows service providers to implement a pay-as-you-grow model when scaling core and edge network capacities.
The S9701-82DC disaggregated open router uses the Broadcom J2C silicon, which provides 4GB packet buffer, 1000Mpps packet throughput and 2.4Tbs switching capacity. It includes an optional knowledge-based processor (or TCAM) to perform up to 16 parallel searches to reach decision speeds of multiple billion decisions per second, which makes it ideal for provider edge applications.  In addition, the S9701-82DC comes with integrated timing interfaces (GNSS, 10MHz, 1PPS, and ToD) with support for IEEE1588v2 and SyncE timing synchronization with Class C accuracy for modern network applications.

S9701-82DC - 25/100G Disaggregated Core and Edge Router
https://www.epsglobal.com/getmetafile/8fca053e-c259-4c7f-a809-d5847c433493/S9701-82DC-1?maxsidesize=400

The UfiSpace S9701-82DC is a high density 25GE disaggregated open router that evolves the network and enables next generation of 5G services and applications. The S9701-82DC can be deployed as a standalone device or within a core switching cluster as a "line card" element within the distributed disaggregated chassis, also known as a DDBR (Distributed Disaggregated Backbone Router).

S9701-82DC
New
S9701-82DC
ufiSpace
https://www.epsglobal.com/getmetafile/d12990ae-2a23-456e-8f8c-1604875b0cc9

Pricing Table

Technical Specification

Features:
  • Disaggregated Open Router (DOR)
  • Distributed Disaggregated Chassis (DDC) “Line Card” white box
  • Processor: Intel Skylake-D 8 Core @ 1.9GHz
  • Memory: 32GB DDR4 R-DIMM with ECC
  • Storage: 128GB SSD
  • 64 x 25GE SFP28 service ports
  • 12 x 100GE QSFP28 service ports
