LAN9500 - USB 2.0 to 10/100 Ethernet Bridge
LAN9500

LAN9500 - USB 2.0 to 10/100 Ethernet Bridge

Manufacturer: Microchip

Datasheet: LAN9500

Delivers to:

Delivers Worldwide.

Contact us for volume discounts.


Authorized Distributor

Stock Availability

Volume Discounts

Technical Support

Includes Warranty

Product Detail

Status: Mature Product Consider: LAN9500A
Microchip's LAN9500 and LAN9500A Hi-Speed USB 2.0 to 10/100 Ethernet controllers provide a high-performance, cost-competitive USB to Ethernet connectivity solution containing an integrated 10/100 Ethernet PHY, Hi-Speed USB 2.0 PHY, Hi-Speed USB 2.0 controller, 10/100 Ethernet MAC, TAP controller, EEPROM controller and FIFO controller in a compact 56-pin QFN package.

LAN9500 - USB 2.0 to 10/100 Ethernet Bridge
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/LAN9500.jpg?ext=.jpg&maxsidesize=400

Microchip's LAN9500 and LAN9500A Hi-Speed USB 2.0 to 10/100 Ethernet controllers provide a high-performance, cost-competitive USB to Ethernet connectivity solution containing an integrated 10/100 Ethernet PHY, Hi-Speed USB 2.0 PHY, Hi-Speed USB 2.0 controller, 10/100 Ethernet MAC, TAP controller, EEPROM controller and FIFO controller in a compact 56-pin QFN package.

LAN9500
New
LAN9500
Microchip
https://www.epsglobal.com/getmetafile/915ba3d8-2a09-413b-ac56-1b8b793defba

Pricing Table

Technical Specification

Ethernet Bandwidth:
10/100Mbps
PHY:
Yes
Downstream Ethernet/USB Ports:
Ethernet x1
Interface:
USB2.0
Status:
Mature Product Consider: LAN9500A
Automotive Grade:
No
MAC:
Yes
Interrupt Pin:
No
LEDs:
3
Op. Voltage (V):
3.3
I/O Pins:
0
Wake-on-LAN:
Yes
EEE:
No
Temp Range Min. (°C):
-40
Temp Range Max. (°C):
85
Packages:
Please call for package information
