LAN91C110 - 10/100 Base-T/TX Ethernet Controller with 16/32 Bit Interface
LAN91C110

LAN91C110 - 10/100 Base-T/TX Ethernet Controller with 16/32 Bit Interface

Manufacturer: Microchip

Datasheet: LAN91C110

Delivers to:

Delivers to Europe.

Contact us for volume discounts.


Authorized Distributor

Stock Availability

Volume Discounts

Technical Support

Includes Warranty

Product Detail

Status: Mature Product Consider: LAN9220
The LAN91C110 is designed to facilitate the implementation of second generation Fast Ethernet PC Card adapters and other non-PCI connectivity products. The LAN91C110 is a digital device that implements the Media Access Control (MAC) portion of the CSMA/CD protocol at 10 and 100 Mbps, and couples it with a lean and fast data and control path system architecture to ensure that the CPU to packet RAM data movement does not cause a bottleneck at 100 Mbps. The LAN91C110 implements a generic 16-bit host interface which is adaptable to a wide range of system buses and CPUs. This makes the LAN91C110 ideal for 10/100 Fast Ethernet implementations in systems based on system buses other than PCI. Total memory size is 128 Kbytes, equivalent to a total chip storage (transmit plus receive) of 64 outstanding packets. The LAN91C110 is software compatible with the LAN9000 family of products in the default mode and can use existing LAN9000 drivers (ODI, IPX, and NDIS) with minor modifications in 16 and 32 bit Intel X86 based environments. Memory management is handled using a unique MMU (Memory Management Unit) architecture and a 32 bit wide data path. This I/O mapped architecture can sustain back-to-back frame transmission and reception for superior data throughput and optimal performance. It also dynamically allocates buffer memory in an efficient buffer utilization scheme, reducing software tasks and relieving the host CPU from performing these housekeeping functions. The total memory size is 128 Kbytes (external), equivalent to a total chip storage (transmit and receive) of 64 outstanding packets. FEAST provides a flexible slave interface for easy connectivity with industry-standard buses. The host interface is "ISA-like" and is easily adapted to a wide range of system and CPU buses. An IEEE-802.3 compliant Media Independent Interface (MII) is provided on the network side of the LAN91C110. The MII interface allows the use of a wide range of MII compliant physical layer (PHY) devices to be used with the LAN91C110. The LAN91C110 also provides an interface to the two-line MII serial management protocol.*The LANCheck online design review service is subject to Microchip's Program Terms and Conditions and requires a myMicrochip account.

LAN91C110 - 10/100 Base-T/TX Ethernet Controller with 16/32 Bit Interface
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/LAN91C110.jpg?ext=.jpg&maxsidesize=400

The LAN91C110 is designed to facilitate the implementation of second generation Fast Ethernet PC Card adapters and other non-PCI connectivity products.

LAN91C110
New
LAN91C110
Microchip
https://www.epsglobal.com/getmetafile/915ba3d8-2a09-413b-ac56-1b8b793defba

Pricing Table

Technical Specification

Ethernet Bandwidth:
10/100Mbps
Interface:
16 bit PCMCIA and Host Bus
PHY:
Yes
TX/RX RAM Buffer(Bytes):
External 128K
Status:
Mature Product Consider: LAN9220
MAC:
Yes
Automotive Grade:
No
Fiber Support:
No
Interrupt Pin:
1
IEEE 1588:
No
WOL:
No
EEE:
No
LEDs:
0
Cable Diag:
No
Op. Voltage (V):
0
Vdd I/O (V):
5
Temp Range Min. (°C):
0
Temp Range Max. (°C):
70
Packages:
Please call for package information
