Netropy 100G WAN Emulator

Manufacturer: Apposite

Datasheet: N100G-100G

Delivers to:

Delivers to Europe.

Contact us for volume discounts.

Status:

Authorised Distributors
Authorized Distributor
Stock
Stock Availability
Bulk Discounts
Volume Discounts
Support
Technical Support
Warranty
Includes Warranty

Product Detail

The Apposite 100G Network WAN Emulator is the perfect solution for testing and validating network performance in a wide variety of scenarios. This device features two QSFP28+ Ethernet ports, a maximum aggregate throughput of 150 Gbps, and an emulation engine that supports up to 100 Gbps. With a maximum packet rate of 32 million pps, and a maximum frame size of 9 KB, the Apposite 100G is capable of packet classification based on IP source & destination address range (IPv4 or IPv6), VLAN, TCP or UDP port number, IP ToS, MAC address, MPLS label, or any other packet contents. Bandwidth can be adjusted from 100 bps to 100 Gbps in 1 bps increments, and delay can be adjusted from 0 ms to 10,000 ms or greater in each direction in 0.01 ms increments, with the option of constant, uniform, or normal distributions. Loss and corruption can be set to random, burst, periodic, BER, Gilbert-Elliott, or recorded loss, and data corruption, network outages, and background utilization can be set from 0-100% in increments of 0.1%. The Apposite 100G also offers RED or tail drop queue management, priority or round robin queuing, and PCAP replay.

Netropy 100G WAN Emulator
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/apposite/N100G-100G.jpg?ext=.jpg&maxsidesize=400
N100G-100G
New
N100G-100G
0.00
Apposite
https://www.epsglobal.com/getmetafile/87de97f4-771b-4c80-91d9-5233d8a48f3a

Features & Benefits

  • Feature 1 Multiple Links: Simulate up to 30 separate WAN links through each Emulation Engine.
  • Feature 2 Packet Filtering: Assign packets to different links by IP address, VLAN, or any other packet identifier.
  • Feature 3 Bandwidths up to 100 Gbps: Precisely emulate links from 100 bits per second up to 100 Gbps.
  • Feature 4 Latency up to 20 sec: Emulate delay and jitter of 10 seconds or more in each direction, in increments of 0.01 ms.
  • Feature 5 Flexible Interfaces: The N61 and N91 emulators are available with copper or SFP ports. The 10G1 and 10G2 offer 1/10 Gbps dual rate SFP+ ports for easy integration into 1 or 10 Gbps networks.
  • Feature 6 Loss & Corruption: Set random, burst, or periodic packet loss. Test the effects of corruption on voice and video applications.
  • Feature 7 Capture & Replay: Record the delay and loss characteristics of a production network as they vary second-by-second and replay them through the Netropy network emulator.
  • Feature 8 Traffic Monitor: View and download up to 24 hours of throughput graphs and link statistics.
  • Feature 9 Automated Testing: Automate application performance testing with Apposite's comprehensive command line interface (CLI).

Technical Specifications

Additional ParametersPacket Reordering, Packet Duplication, MTU and Fragmentation, Queue Depth, Framing Overhead
Background Utilization0 - 100% in increments of 0.1%; PCAP replay
Bandwidth100 bps - 100 Gbps in 1 bps increments (depending on model)
Delay0 ms - 10, 000 ms or greater in each direction in 0.01 ms increments; constant, uniform, normal distributions; replay recorded loss, accumulate & burst
Emulation Engines1 @ 100 Gbps
Ethernet Ports2x QSFP28+; 100Gbps
Hardware WarrantyHardware warranty is included with product license
Loss & CorruptionRandom, burst, periodic, BER, Gilbert-Elliott, or recorded loss; data corruption; network outage
Management1 x Gigabit Ethernet, 1 x RS-232 serial console
Max. Agg. Throughput150 Gbps
Maximum Frame Size9 KB
Maximum Packet Rate32 million pps
Packet ClassificationIP source & destination address range (IPv4 or IPv6), VLAN, TCP or UDP port number, IP ToS, MAC address, MPLS label, or any other packet contents
Power SupplyRedundant
Product License 1-YrN100G-R1YR
Product License 3-YrN100G-R3YR
Queuing & PrioritizationRED or tail drop queue management; priority or round robin queuing
SecuritySSL and SSH for secure management; per-user locking of engine configuration
Support & MaintenanceSupport is included with product license and software maintenance
-->
