WaveShaper-M
WaveShaper® M Series
WaveShaper-M

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Designed for OEM Integration
  • Fully compatible with benchtop Series
  • Control of Filter Shape
  • Control of Filter Dispersion (applies for 1000A / 4000A / 16000A)
  • High Resolution
  • Small Form Factor
  • USB and Ethernet Interface
  • Integrated Webserver allows platform independent control
WaveShaper® M Series
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-M.jpg?ext=.jpg&maxsidesize=400
WaveShaper M Series Processors are the OEM versions of the WaveShaper instruments.
WaveShaper-M
WaveShaper-M
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveShaper-1000A
WaveShaper® 1000A Programmable Optical Filter
WaveShaper-1000A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Based on High Resolution Liquid Crystal on Silicon (LCoS) technology
  • Arbitrary Filter Shape
  • Control of Filter Dispersion
  • 35 dB Attenuation Control
  • Filter bandwidth variable from 10 GHz to 9 THz, depending on model
  • Integrated Webserver allows platform independent control
Application :
  • Optical Component Testing
  • Transceiver Testing
  • DWDM System Testing
  • Laser Pulse Compression
  • Optical/Microwave Filtering
WaveShaper® 1000A Programmable Optical Filter
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-1000A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveShaper 1000A Programmable Optical Filter supports arbitrary user-generated channel and filter shapes.</p>
WaveShaper-1000A
WaveShaper-1000A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveShaper-100A
WaveShaper® 100A Tunable Optical Filter
WaveShaper-100A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Variable-bandwidth tunable optical filter
  • No moving parts
  • Centre frequency settable in 1 GHz steps
  • Filter bandwidth variable from 10 GHz to 1000 GHz
  • Built-in Flat-top and Gaussian filter shapes
  • Integrated Webserver allows platform independent control
Application :
  • Optical Component Testing
  • Transceiver Testing
  • DWDM System Testing
  • Channel Selection
WaveShaper® 100A Tunable Optical Filter
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-100A.jpg?ext=.jpg&maxsidesize=400
The WaveShaper 100A is a variable-bandwidth tunable optical filter which is optimized for use in R&D as well as in production test applications where the precise control over both the bandwidth and the center frequency ensures support for current test requirements as well as for next generation FlexgridTM-based networks and subsystems.
WaveShaper-100A
WaveShaper-100A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveAnalyzer-100S
WaveAnalyzer 100S Compact Optical Spectrum Analyzer
WaveAnalyzer-100S

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Full C-band coverage
  • Resolution bandwidth: 1.8 GHz (about 14 pm)
  • Compact: 108 x 163 x 26 mm3
  • Fast: 2 updates per second
Application :
  • Spectral analysis in system test
  • Gain equalization
  • Optical Signal to Noise Ratio (OSNR) measurement
  • WDM analysis
WaveAnalyzer 100S Compact Optical Spectrum Analyzer
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveAnalyzer-100S.jpg?ext=.jpg&maxsidesize=400
The WaveAnalyzer 100S Compact Optical Spectrum Analyzer is a small, lightweight instrument which has been designed for spectral measurements on advanced optical communication systems in R&D and manufacturing.
WaveAnalyzer-100S
WaveAnalyzer-100S
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveShaper-16000A
WaveShaper® 16000A Reconfigurable Optical Processor
WaveShaper-16000A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Port configuration: 1 x 19, 4 x 16, 8 x 12, 10 x 10
  • Based on High Resolution Liquid Crystal on Silicon (LCoS) technology
  • Arbitrary Filter Shape
  • Control of Filter Dispersion
  • 35 dB Attenuation Control
  • Filter bandwidth variable from 10 GHz up to 5 THz
  • Power Splitting of Channels to Multiple Output Ports
  • FlexGrid Channel Emulator Software
  • Integrated Webserver allows platform independent control
Application :
  • SDN (Software Defined Networking) System Test
  • Research on Elastic Optical Networks
  • Optical OFDM
  • Multiplexing / DeMultiplexing
  • Optical Component Emulation
  • DWDM System Testing
  • Flexgrid System Development
WaveShaper® 16000A Reconfigurable Optical Processor
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-16000A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveShaper 16000A Multiport Optical Processor is a programmable 4x16 wavelength-selective optical switch and filter with control of filter shape and phase on each input/outport port combination.</p>
WaveShaper-16000A
WaveShaper-16000A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveAnalyzer 200A
WaveAnalyzer 200A Portable Optical Spectrum Analyzer
WaveAnalyzer 200A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Full C-band coverage
  • Resolution bandwidth: 1.75 GHz
  • Fast: >1 updates per second
  • Battery operated
  • Remote control via Ethernet
  • No moving parts
Application :
  • System turn up and trouble shooting
  • DWDM testing
  • Channel power and Optical Signal to Noise Ratio (OSNR) testing
  • Channel equalizing
  • Lab, network and data center
WaveAnalyzer 200A Portable Optical Spectrum Analyzer
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveAnalyzer-200A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveAnalyzerTM 200A is a lightweight portable Optical Spectrum Analyzer covering the C-band of optical communications.</p>
WaveAnalyzer 200A
WaveAnalyzer 200A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveShaper-4000A
WaveShaper® 4000A Multiport Optical Processor
WaveShaper-4000A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Based on High Resolution Liquid Crystal on Silicon (LCoS) technology
  • Arbitrary Filter Shape
  • Control of Filter Dispersion
  • Instruments Available for Covering C-band, L-band or C+L-band
  • 35 dB Attenuation Control
  • Filter bandwidth variable from 10 GHz up to 9 THz
  • Power splitting up to 4 ports
  • FlexGrid Channel Emulator Software
  • Integrated Webserver allows platform independent control
Application :
  • Optical Component Emulation
  • Pulse Generation and Manipulation
  • DWDM System Testing
  • Flexgrid System Development
  • Optical/Microwave Filtering
WaveShaper® 4000A Multiport Optical Processor
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-4000A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveShaper 4000A Multiport Optical Processor extends the capability of the WaveShaper 1000A including the ability to direct different portions of the spectrum to different output ports with different, arbitrary user-generated channel shapes for each portion of the spectrum.</p>
WaveShaper-4000A
WaveShaper-4000A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Arbitrarily programmable shape of attenuation and phase
  • Instrument versions available for the 1 µm and in the 1.55 µm band
  • Resolution bandwidth 0.1 nm
  • Group delay adjustable
  • Large attenuation range
  • Single Polarization Operation
  • Fully fiberized with PM pigtails on input and output
  • USB and Ethernet control interface
  • Benchtop and Modular versions available
  • No moving parts; based on LCoS technology
Application :
  • Material Processing
  • Short Pulse Laser Research
  • Medical (Dermatology/Ophthalmology)
  • Microscopy
  • Spectroscopy
  • Coherent Quantum Control
  • Optical Communications
WaveShaper 1000A/SP Programmable Single Polarization Filter, available for 1 µm and 1.55 µm signals
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-1000A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveShaper 1000A/SP is a Polarization Maintaining (PM) programmable filter which provides full control of the amplitude and phase spectra either across the entire C-band or in the 1µm window.</p>
WaveShaper 1000A/SP
WaveShaper 1000A/SP
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar
WaveShaper-500A
WaveShaper® 500A Programmable Optical Filter
WaveShaper-500A

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • Based on High Resolution Liquid Crystal on Silicon (LCoS) technology
  • Arbitrary Attenuation Shape
  • 35 dB Attenuation Control
  • Filter bandwidth variable from 10 GHz to more than 5 THz
  • Integrated Webserver allows platform independent control
Application :
  • Optical Component Testing
  • Transceiver Testing
  • DWDM System Testing
  • Laser Pulse Compression
  • Optical/Microwave Filtering
WaveShaper® 500A Programmable Optical Filter
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveShaper-500A.jpg?ext=.jpg&maxsidesize=400
<p>The WaveShaper 500A Programmable Optical Filter supports arbitrary user-generated channel and filter shapes.</p>
WaveShaper-500A
WaveShaper-500A
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar

Quantity breaks available. View Pricing Table

Pricing Table

Product Highlights :
  • High spectral resolution
  • Real time measurement
  • Update rate: 4 Hz for full C-band scan 10 Hz for scan across any 200 GHz window
  • Spurious-free Dynamic Range > 50 dB
  • Full C-band coverage
  • External Trigger
Application :
  • High-Resolution spectral analysis on optical components
  • Modulation analysis on optical signals
  • Modulator test
  • Modulator bias and polarization adjustments
  • Transceiver test
  • SMSR measurements
  • Network monitoring
WaveAnalyzer 1500S High-Resolution Optical Spectrum Analyzer
https://www.epsglobal.com/Media-Library/EPSGlobal/Products/files/finisar/roadm-fws-optoelectronic/WaveAnalyzer-1500S.jpg?ext=.jpg&maxsidesize=400
The WaveAnalyzer(TM) 1500S is an Optical Spectrum Analyzer offering very high spectral resolution in combination with a fast update rate of 4 measurements per second across the entire C-band or 10 Hz across any 200 GHz window.
WaveAnalyzer-1500S
WaveAnalyzer-1500S
Finisar
https://www.epsglobal.com/getmetafile/38c38d6f-96fa-4ba8-9fe1-f446f11e2e1a/Finisar

Showing 10 of 10 results

Showing 1 - 10 of 10 results
