The S9100-32X is specifically designed for the unique application in high-performance data center environments.

Taking full advantage of non-blocking switching architecture, the S9100-32X significantly reduces head-of-line blocking (HOL blocking) to provide line-rate L2 and L3 forwarding capacity for concurrent support of all ports at full capacity.

For data centers looking to acquire future-ready solutions, simplifying the migration to 100 Gbps in the data core is achieved in a denser footprint while maintaining necessary constraints in a rack space.

The agility to design optimized data center networks is further enhanced with architectural features including:

  • Redundant hot-swappable power supplies
  • Redundant hot-swappable fans

These features provide flexibility, efficiency, and availability for the data center network.

S9100-32X 32 x 100GE QSFP28 Ports
The S9100-32X is a high-performance data center switch with non-blocking architecture, reducing HOL blocking. It supports line-rate L2 and L3 forwarding, facilitates migration to 100 Gbps, and features redundant hot-swappable power supplies and fans.

Features & Benefits

  • Compact full featured modular 10/25/40/50/100GE data center switch
  • 1 x RJ45 console/management port with RS232 signaling
  • 1 x 10/100/1000 Base-T Ethernet for Out-of-Band management
  • 1 x USB 2.0 Type-A port

Technical Specifications

ASICBroadcom BCM56960 (Tomahawk)
Chassis1 RU, 440w x 44h x 406d mm (17.32” x 1.73" x 15.98") Weight : 9.52 kg (20.98 lb)
FAN TraysTwo hot swappable power supplies with integrated fans and trays
Non-Operating Spec.Storage temperature: -40°C to 70°C (-40°F to 158°F) Storage humidity: 5% to 95% (RH), non-condensing
Operating Spec.0°C to 45°C (32°F to 113°F) Operating humidity: 10% to 90% (RH), non-condensing
Power supplyAC input: 100V-240V, 8~4A , 60/50Hz DC input: 240V, 2.75A (240Vdc China only) Typical/Max power draw: 360/420 Watts
ProcessorIntel® Rangeley C2558 2.4G 4-Core
StorageM.2 SSD 64GB
