ion12xi_h2 - Wi-Fi 6 Indoor APs

ion12xi_h2 - Wi-Fi 6 Indoor APs

Manufacturer: IO by HFCL

Datasheet: ion12xi_h2

Delivers to:

Delivers to Europe.

Contact us for volume discounts.


Authorised Distributors
Authorized Distributor
Stock Availability
Bulk Discounts
Volume Discounts
Technical Support
Includes Warranty

Product Detail

Introducing the ion12xi_h2 - Wi-Fi 6 Indoor Access Point, a cutting-edge solution for larger enterprises, high-density indoor environments, shopping malls, schools, and stadiums. This Wi-Fi 6 Indoor AP is Wi-Fi Alliance certified and offers a concurrent dual-band data rate up to 5.95 Gbps, ensuring high-speed connectivity for up to 1024 concurrent users.

The ion12xi_h2 features a 6dBi integrated omnidirectional antenna, optimized for maximum coverage and range. It supports access to a 160 MHz channel in the 5GHz band and is configurable as a 4x4 MU-MIMO in 160 MHz channel bandwidth or 8x8 MU-MIMO in the 80 MHz channel bandwidth, without compromising on peak data rates.

This AP also supports 1024 QAM and non-Wi-Fi interference detection & avoidance, ATPC, and coverage hole detection and correction, ensuring a seamless and uninterrupted connection. It is also equipped with EasyMesh networking, fast roaming, fast handover, and QoS 802.11e WMM (Wi-Fi Multi-Media) for enhanced user experience.

The ion12xi_h2 is not just about speed and performance; it also offers centralized control for easy management and improved battery life for sustained operation. With its dual-band radio offering a peak data rate up to 5.95 Gbps and configurable 5 GHz radio, the ion12xi_h2 is the perfect solution for your high-density connectivity needs.

ion12xi_h2 - Wi-Fi 6 Indoor APs

Features & Benefits

  • Concurrent Dual-Band Offering Data Rate up to 5.95 Gbps
  • 6dBi Integrated Omnidirectional antenna optimized for maximum coverage and range
  • Supports 1024 concurrent users
  • Access to 160 MHz channel in the 5GHz Band
  • Wi-Fi Alliance certified for Wi-Fi 6, Passpoint 3.0, EasyMesh
  • Supports 1024 QAM
  • Supports non-Wi-Fi interference detection & avoidance, ATPC, coverage hole detection and correction
  • Configurable as a 4x4 MU-MIMO in 160 MHz channel Bandwidth or 8x8 MU-MIMO in the 80 MHz Channel Bandwidth, in 5GHz Band without compromising on the peak data rates
  • Dual-Band Radio Offering Peak Data Rate up to 5.95 Gbps
  • Configurable 5 GHz radio
  • Bi-Directional, Multi User-Multiple Input Multiple Output (MU-MIMO)
  • EasyMesh Networking
  • QoS 802.11e WMM (Wi-Fi Multi-Media)
  • Centralized control
  • Improved Battery Life

Technical Specifications

Antenna TypeIntegrated
Max Transmit Power28 dBm
Maximum Concurrent User Support1024
Peak ThroughputUp to 5.95 Gbps
TechnologyWi-Fi 6
WPA2 SecurityYes
WPA3 SecurityYes



IO by HFCL's comprehensive set of products include a full range of Indoor and Outdoor WiFi5 and WiFi6 AccessPoints, P2P and P2mP Unlicensed Band Radios (UBR), Switches and a massively scalable Cloud Network Management System. The entire portfolio has been conceptualized, designed, developed and manufactured in India complying with global specifications with a sole objective to provide ubiquitous connectivity by delivering affordable, interoperable and high-quality wireless Access Solutions for all.
